RAK3401 WisBlock BLE Module
Thank you for choosing RAK3401 WisBlock BLE Module in your awesome IoT Project! 🎉 To help you get started, we have provided you with all the necessary documentation for your product.
- RAK3401 Quick Start Guide
- Datasheet
- WisBlock Quick Start Guide
- WisBlock Source Code Repository
- Arduino IDE BSP
- PlatformIO BSP
- Bootloader source code and ready to flash file
- RAK3401 3D Model
- 40-Pin Male Connector 3D File
Product Description​
RAK3401 is a WisBlock Core module for RAK WisBlock. It extends the WisBlock series with a powerful Nordic nRF52840 MCU that supports Bluetooth 5.0 (Bluetooth Low Energy). This makes the RAK3401 an ultra-low power communication solution. RAK3401 can be comfortably programmed with the Arduinoâ„¢ IDE or the PlatformIO extension for other IDE's like Atom, MS Visual Code, or Clion.
Product Features​
-
Nordic nRF52840 ultra-low power MCU
-
32-bit ARM® Cortex™-M4 CPU
-
64Â MHz CPU clock
-
1Â MB Flash, 256Â KB RAM
-
Bluetooth 5.0 protocol stack
-
I2C, SPI, Analog inputs, Digital inputs, and outputs
-
Low power consumption
-
Chipset: Nordic nRF52840
Prerequisites​
To use a RAK3401, you need at least a WisBlock Base to plug the module in. WisBlock Base is the power supply for the RAK3401 module and has the programming/debug interface.
- Make sure to fix the module with the screws to ensure a proper function.
- When using the Bluetooth Low Energy transceiver, make sure that always an antenna is connected. Using these transceivers without an antenna can damage the system.
