RAK7201V2 WisNode Button 4K

Thank you for choosing RAK7201V2 WisNode Button 4K in your awesome IoT project! 🎉 To help you get started, we have provided you all the necessary documentation for your product.

• Quick Start Guide
• AT Command Manual
• Firmware Upgrade Guide
• Datasheet

Product Description

The RAK7201V2 WisNode Button 4K is a remote wireless trigger device. It supports a user-defined payload for each key and is based on the LoRaWAN 1.0.3 protocol. LoRaWAN bands supported include IN865, EU868, AU915, US915, KR920, and AS923.

With its long-range wireless connectivity, impressive battery life, and four programmable buttons, this device is suitable for a wide range of applications. The Button is suitable for a variety of Smart Home applications, including entertainment system control, light control, an alarm snooze button, and a remote trigger.

Product Features

• Four (4) Buttons with LED indicator
• Based on the RAK3172 module
• Product Size: 43x57x15 mm
• LoRaWAN 1.0.3 specification-compliant
• Battery: 400 mAh
• Battery Over Current Protection and Over-Temperature Protection
• Power Consumption: Sleep mode is 6.25 uA @ 4.2 V
• Operating Temperature: -10º C to 60º C
• Working Environment: Indoor
