RAK10708 WisMesh Pod

Product Description

The RAK10708 WisMesh Pod is a compact, ready-to-use Meshtastic node. It features a robust injection-molded enclosure, a built-in 1,000 mAh rechargeable battery, and integrated antennas for LoRa, BLE, and GNSS. With no assembly required, the WisMesh Pod provides a convenient solution for off-grid mesh communication.

Key Features

• Integrated nRF52840 + SX1262: Nordic MCU and Semtech LoRa transceiver built directly into the mainboard
• AT6558 GNSS Module: Fast and accurate GPS positioning
• LIS2DH 3-AXIS Accelerometer Sensor: Optional wake/sleep behavior or motion-based triggers
• USB Type-C Charging, Status LEDs (BLE, heartbeat, charging)
• Multifunctional Button: Power ON/OFF, Reset, DFU
• Integrated Antennas: No assembly needed, just better performance
• Compact size and ready to mount
• Wide frequency range: Supports 860–930 MHz with a single WisMesh Pod hardware version.
• Buzzer:
  • ​​Maximum sound pressure level: 85 dB
  • Maximum current: 95 mA

Typical Applications

• Outdoor Trekking: While trekking through remote mountain trails, a group uses WisMesh Pods to maintain communication. The sealed, rugged design ensures the device continues working even in heavy rain and harsh terrain.
• Emergency Response: Emergency responders in a natural disaster zone deploy WisMesh Pods to set up a fast, temporary communication network. Thanks to the pre-flashed firmware and intuitive setup, the team stays organized and safe.
