Modular IoT Boards

WisBlock is an amazing product built by the RAK company for the IoT industry. Its modular approach solutions are built like clicking blocks together to realize your ideas making it easier to implement to low power wide area network (LPWAN) into your IoT solution.

---

Getting Started with the WisBlock Modular System

WisBlock Ecosystem

---

WisBlock is build up on a WisBlock Base board, a platform carrier that allows easy plug-in of one WisBlock Core processing board and multiple WisBlock modules. WisBlock Base provides the power supply, battery and solar panel supplies and charging block. In addition, it has connectors for programming and debugging.

RAK19001 is a full WisBlock Base board that has one Core slot, two IO slots, and six sensor slots for WisBlock modules. It also provides the power supply for attached WisBlock modules.

WisBlock Dual IO Base Board

Model: RAK19001

RAK19003 is a mini base board that connects a WisBlock Core and two WisBlock modules together. It also provides the power supply for the attached WisBlock modules.

WisBlock Mini Base Board

Model: RAK19003

RAK19007 WisBlock Base Board 2nd Gen is the new base board that allows you to attach WisBlock modules. In addition, this board also comprises a Type-C USB connector, indicator LEDs, buttons, and sensor connectors.

WisBlock Base Board 2nd Gen

Model: RAK19007

RAK19009 is a mini base board that connects a WisBlock Core and two WisBlock modules together. It also provides the power supply for the attached WisBlock modules.

WisBlock Mini Base Board with Power Slot

Model: RAK19009

RAK19010 is a WisBlock Base Board with Power Slot that allows you to attach WisBlock modules in four sensor slots and one IO slot.

WisBlock Base Board with Power Slot

Model: RAK19010

RAK19011 is a full WisBlock Dual IO Base Board with Power Slot that has one Core slot, one Power Slot, two IO slots, and six sensor slots for WisBlock modules. It also provides the power supply for attached WisBlock modules.

WisBlock Dual IO Base Board with Power Slot

Model: RAK19011

RAK19012 is a WisBlock USB LiPo Solar Power Slot Module that comprises a USB C connector, a Li-Po battery connector with an onboard charger, a solar panel connector, a reset push button, a charging LED status, and a power connector that can connect with the WisBlock Base board.

WisBlock USB LiPo Solar Power Slot Module

Model: RAK19012

RAK19013 is a WisBlock LiPo Solar Power Slot Module that comprises a battery connector, a solar panel connector, a reset push button, a charger circuitry, a charging LED status, and a power connector that can connect with the WisBlock Base board.

WisBlock LiPo Solar Power Slot Module

Model: RAK19013

RAK19014 is a WisBlock Power module that comprises a battery connector and a USB Type-C connector which can connect to the WisBlock Base board with Power Slot.

WisBlock Battery USB Power Slot Module

Model: RAK19014

RAK19015 is a WisBlock Power module that comprises a battery connector, a reset push button, and a power connector which can connect with WisBlock Base board.

WisBlock Battery Power Slot Module

Model: RAK19015

RAK19016 is a WisBlock 5-24V Power Slot Module. It comprises a 3-pin screw terminal connector, Li-Po battery connector, an on-board charger, LED charge indicator, two user-configurable LEDs, a reset button, and a power connector that can connect with the WisBlock Base board.

WisBlock 5-24 V Power Slot Module

Model: RAK19016

RAK19017 is a WisBlock POE Slot Module. It comprises an Ethernet connector and a reset button that can connect with the WisBlock Base board via 40-pin power slot connector.

WisBlock POE Slot Module

Model: RAK19017

List of WisBlock Base Board Legacy Products

End-of-Life Products

Model: WisBlock Base Board

WisBlock Core is the processing unit of your IoT solution. Select a module matching the requirements of your application. Available modules include low power single core MCU’s and fast dual core MCU’s. Different WisBlock Core modules offer different communication possibilities like LoRa, WiFi, BLE and/or Bluetooth.

RAK11200 is a WisBlock Core module for RAK WisBlock. It extends the WisBlock series with an Espressif ESP32-WROVER module that supports WiFi-BLE functions and supplies a powerful MCU for a wide variety of applications.

WisBlock WiFi Module

Model: RAK11200

RAK11310 is a WisBlock Core module for RAK WisBlock. It is powered by an RP2040 ARM Microcontroller developed by the Raspberry Pi Foundation combined with the SX1262 LoRa transceiver from Semtech.

WisBlock LPWAN Module

Model: RAK11310

The RAK11722 is a WisBlock Core module within the RAK WisBlock ecosystem, featuring firmware based on RUI3. It enhances the series with an Ambiq Apollo3 SoC MCU that supports Bluetooth 5.0 (BLE) and integrates the latest LoRa transceiver from Semtech, the SX1262.

WisBlock LPWAN Module

Model: RAK11722

RAK3372 is a WisBlock Core module for RAKwireless WisBlock. It extends the WisBlock series with a very efficient core based on STM32WL LoRa SoC which supports LoRa P2P and LoRaWAN functionality.

WisBlock LPWAN Module

Model: RAK3372

RAK4631-R is a WisBlock Core module for RAK WisBlock. It extends the WisBlock series with a powerful Nordic nRF52840 MCU that supports Bluetooth 5.0 (Bluetooth Low Energy) and the newest LoRa transceiver from Semtech, the SX1262. RAK4631-R firmware is based on RUI3.

WisBlock LPWAN Module

Model: RAK4631-R

RAK4631 is a WisBlock Core module for RAK WisBlock. It extends the WisBlock series with a powerful Nordic nRF52840 MCU that supports Bluetooth 5.0 (Bluetooth Low Energy) and the newest LoRa transceiver from Semtech, the SX1262.

WisBlock LPWAN Module

Model: RAK4631

WisBlock Wireless Modules extend the communication capabilities of WisBlock with the offered WiFi and cellular modem modules. Also, these modules can fit into the IO slot of the WisBlock Base Boards.

RAK2305 is a WisBlock Wireless module that extends the WisBlock system with Wi-Fi and Bluetooth connectivity. It is based on the Espressif ESP32 WROVER module.

WisBlock Wireless Module

Model: RAK2305

RAK5860 is a WisBlock Wireless module that extends the WisBlock system with LTE NB-IoT connectivity. It is based on the Quectel BG77 module and supports CAT M1 and CAT NB2 connectivity.

WisBlock NB-IoT Interface Module

Model: RAK5860

RAK13101 is a WisBlock Wireless module that extends the WisBlock system to have GSM/GPRS Cellular Network capability using Quectel MC20CE module.

WisBlock GSM/GPRS Module

Model: RAK13101

RAK13102 is a WisBlock IO module for the Blues.IO Notecards.

WisBlock Blues Notecarrier Module

Model: RAK13102

The RAK13300 is a LoRa module based on the SX1262 LoRa chip that provides an easy-to-use, small-size, low-power solution for long-range wireless data applications.

WisBlock LPWAN Wireless Module

Model: RAK13300

RAK13600 is a WisBlock NFC Reader module that enables WisBlock projects to scan NFC and RFID-enabled devices, as well as tags.

WisBlock NFC Reader Module

Model: RAK13600

RAK13801 is a WisBlock IO that extends the WisBlock system based on Decawave's DW1000 module. This module uses a UWB (Ultra Wideband) Technology, a short-range wireless communication similar to Wi-Fi or Bluetooth, and it uses a frequency bandwidth above 1 GHz.

WisBlock UWB Module

Model: RAK13801

WisBlock Sensor offers a range of sensors for sensing environmental conditions (temperature and humidity), location, and movement conditions (GNSS location and accelerometer). They are easy to install just by plugging them into the WisBase to complete your application with the required sensors.

RAK12001 is a Fingerprint Sensor that can read and record fingerprints.

WisBlock Fingerprint Sensor Module

Model: RAK12001

RAK12003 is a WisBlock Infrared Temperature Sensor which extends the WisBlock system with a non-contact IR thermal sensor. A ready to use software library and tutorial makes it easy to add a thermal sensor to your project.

WisBlock Infrared Temperature Sensor Module

Model: RAK12003

RAK12004 is a WisBlock Sensor Module that extends the WisBlock system with a gas sensor. It enables the user to build a gas and smoke detection system that can send measured data and alarm messages over LoRaWAN.

WisBlock MQ2 Gas Sensor Module

Model: RAK12004

RAK12005 is a WisBlock Sensor that contains a sensing pad used for detecting water like rain and other electroconductive liquids.

WisBlock Rain Sensor Module

Model: RAK12005

RAK12006 is a Pyroelectric Infrared Radial (PIR) module designed to detect occupancy and motion.

WisBlock PIR Sensor Module

Model: RAK12006

RAK12007 is a WisBlock Ultrasonic Module which extends the WisBlock with a ultrasonic object detector. A ready to use SW library and tutorial makes it easy to add an object detector to your project.

WisBlock Ultrasonic Sensor Module

Model: RAK12007

RAK12008 is a WisBlock CO2 Sensor Module that extends the WisBlock system with a Sensirion STC31 CO2 Sensor. A ready-to-use SW library and tutorial make it simple to build a CO2 gas data acquisition system for high CO2 concentrations

WisBlock CO2 Sensor

Model: RAK12008

RAK12009 is a WisBlock Sensor Module that extends the WisBlock system with an Alcohol Gas sensor. It enables the user to build an Alcohol detection system that can send measured data and alarm messages over LoRaWAN.

WisBlock MQ3 Alcohol Gas Sensor Module

Model: RAK12009

RAK12010 is a WisBlock Sensor that extends the WisBlock system to have ambient light sensing capability. It uses the VEML7700 chip from Vishay Semiconductors with an I2C interface making it easy to build an ambient light data acquisition system.

WisBlock Ambient Light Sensor Module

Model: RAK12010

RAK12011 is a WisBlock Sensor that extends the WisBlock system with a water-resistant pressure sensor of LPS33HW. This makes it easy to build up a barometric air pressure data acquisition system even in a wet environment.

WisBlock Barometer WT Sensor Module

Model: RAK12011

RAK12012 is a WisBlock Sensor that can measure pulse oximetry and heart rate of a person.

WisBlock WisBlock Heart Rate Sensor Module

Model: RAK12012

RAK12013 is a WisBlock sensor that applies the Doppler radar effect to detect moving objects/motion using microwaves at a 360 degrees angle within 7 meters radius.

WisBlock Radar Sensor Module

Model: RAK12013

RAK12014 is a Time-of-Flight (TOF) module designed based on VL53L0X from STMicroelectronics. With this, RAK12014 can measure absolute range up to 2 meters.

WisBlock ToF Sensor Module

Model: RAK12014

RAK12015 uses a high-precision vibration sensor, the ANT-801S. This sensor is capable of detecting micro shocks or vibration without direction limits.

WisBlock Vibration Detection Sensor Module

Model: RAK12015

RAK12016 is a flex sensor module that uses an FS-L-0095-103-ST from Spectrasymbol, which can measure the amount of deflection or bending.

WisBlock Flex Sensor Module

Model: RAK12016

RAK12017 is an IR Detection Module that can detect if IR Signal is reflected back.

WisBlock IR Detection Sensor Module

Model: RAK12017

RAK12019 is an Ambient Light Sensor (ALS) or Ultraviolet Light Sensor (UVS). It measures the ambient light intensity and ultraviolet index, which is interfaced via the I2C bus, making it immune to electrical noises.

WisBlock UV Sensor

Model: RAK12019

RAK12020 is a WisBlock Light Sensor module that extends the WisBlock system with a TSL25911FN Light Sensor from AMS. A ready-to-use SW library and tutorial make it simple to build an ambient light-intensity data acquisition system.

WisBlock Light Sensor

Model: RAK12020

RAK12021 is a WisBlock RGB Sensor that extends the WisBlock system which is based on TCS37725FN from AMS. The Red, Green, Blue, and Clear (RGBC) light sensing can be obtained via I2C interface.

WisBlock RGB Sensor Module

Model: RAK12021

RAK12022 is a PT100 IO module that uses MAX31865, an easy-to-use resistance-to-digital converter optimized for platinum resistance temperature detectors (RTDs).

WisBlock PT100 Module

Model: RAK12022

RAK12023 is a WisBlock soil connector module where you can connect the separate sensor PCB, which is the RAK12035 Soil Moisture sensor.

WisBlock Soil Moisture Sensor Connector Module

Model: RAK12023

RAK12025 is a WisBlock Core module for RAKwireless WisBlock. It extends the WisBlock series with a very efficient core based on STM32WL LoRa SoC which supports LoRa P2P and LoRaWAN functionality.

WisBlock LPWAN Module

Model: RAK12025

RAK12027 is a WisBlock Earthquake Sensor Module based on D7S, the world’s smallest high-precision seismic sensor from Omron. It detects earthquake seismic intensity.

WisBlock Earthquake Sensor Module

Model: RAK12027

RAK12028 is a WisBlock T-Beam-Fork connector module where you can connect the separate sensor PCB - the RAK12031 WisBlock T-Beam-Fork Sensor Module.

WisBlock T-Beam-Fork Connector Module

Model: RAK12028

RAK12029 is a WisBlock Sensor Module that extends the WisBlock system with an inductive sensor. It enables the user to build a metallic detection system that can send measured data and alarm messages over LoRaWAN.

WisBlock Inductive Sensor Module

Model: RAK12029

RAK12031 is a WisBlock T-Beam-Fork (TBF) sensor module based on EE-SX1041 from Omron. It can detect the presence of small moving objects.

WisBlock T-Beam-Fork Sensor Module

Model: RAK12031

RAK12032 is a WisBlock 3-axis Accelerometer Sensor Module that extends the WisBlock system with an ADXL313 3-axis accelerometer from Analog Devices. A ready-to-use SW library and tutorial make it simple to build a motion-sensing data acquisition system.

WisBlock 3-Axis Accelerometer Sensor

Model: RAK12032

RAK12033 is a WisBlock 6-axis Accelerometer sensor module based on IIM-42652 from TDK InvenSense. It is a motion tracking device that supports an extended operating temperature range.

WisBlock 6-Axis Accelerometer Sensor Module

Model: RAK12033

RAK12034 is a 9-axis accelerometer module, part of the RAKwireless WisBlock Sensor series. It is based on BMX160 Bosch Sensor, which is a highly integrated low-power 9-axis sensor providing precise acceleration, angular rate, and geomagnetic measurement in each spatial direction.

WisBlock 9-Axis Accelerometer Module

Model: RAK12034

RAK12035 is a WisBlock soil moisture sensor probe that uses capacitive sensing to measure the amount of moisture around the soil.

WisBlock Soil Moisture Sensor Module

Model: RAK12035

RAK12037 is a WisBlock Sensor that extends the WisBlock system based on the SCD30 module, which can sense C02 and has an integrated temperature and humidity sensor. A ready-to-use SW library and tutorial make it easy to build up an environmental data acquisition system.

WisBlock CO2 Sensor Module

Model: RAK12037

RAK12039 is a WisBlock Sensor Module that extends the WisBlock system with Particle Matter sensing. It is based on PMSA003I digital particle concentration sensor, which obtains the number of suspended particles in the air.

WisBlock Particle Matter Module

Model: RAK12039

RAK12040 is a WisBlock 8x8 IR Sensor Module that extends the WisBlock system with an AMG8833 chip from Panasonic. It comes with a ready-to-use software library and tutorial, making it easy to build up a temperature data acquisition system.

WisBlock 8x8 IR Sensor

Model: RAK12040

RAK12044 is a WisBlock Hall Effect Sensor module that extends the WisBlock system with a DRV5056A4QDBZR Hall Sensor from Texas Instruments. It comes with a ready-to-use software library and tutorial, making it easy to build a magnetic field data acquisition system.

WisBlock Hall Effect Sensor

Model: RAK12044

RAK12047 is a WisBlock Sensor that extends the WisBlock system with a SGP40 from SENSIRION. A ready-to-use SW library and tutorial make it easy to build a Volatile Organic Compounds (VOC) sensor intended for air quality data acquisition system.

WisBlock VOC Sensor Module

Model: RAK12047

RAK12052 is a 32x24 thermal IR array module based on MLX90640 from Melexis. MLX90640 is a fully-calibrated 32x24 pixels thermal IR array in an industry-standard 4-lead TO39 package with a digital interface. The MLX90640 contains 768 FIR pixels.

WisBlock Thermal IR Array Module

Model: RAK12052

RAK12054 is a WisBlock Encoder Sensor module that extends the WisBlock system with an AS5600-ASOT Encoder Sensor from OSRAM. It comes with a ready-to-use software library and tutorial, making it easy to build a magnetic rotary position data acquisition system.

WisBlock Encoder Sensor

Model: RAK12054

RAK12059 is a WisBlock Liquid Level Sensor module that extends the WisBlock system with a Liquid Level Sensor from MILONE. It comes with a ready-to-use software library and tutorial, making it easy to build a liquid level data acquisition system.

WisBlock Liquid Level Sensor

Model: RAK12059

RAK12500 is a full WisBlock sensor board that has one Core slot, two IO slots, and six sensor slots for WisBlock modules. It also provides the power supply for attached WisBlock modules.

WisBlock GNSS Location Module

Model: RAK12500

RAK13011 is a Magnetic Switch Sensor module, part of the WisBlock Sensor Series. This sensor is essentially a reed switch assembly consisting of a magnet and a reed switch whose contacts are normally open.

WisBlock Magnetic Switch Sensor Module

Model: RAK13011

RAK14008 is a WisBlock sensor module that extends the WisBlock system. It is based on PAJ7620U2, which integrates gesture recognition function with a general I2C interface into a single chip.

WisBlock Gesture Sensor Module

Model: RAK14008

RAK16000 is a part of the WisBlock Sensor Series that is capable of measuring DC current in the range of 0 to 3A in a voltage range of 0 to 26V.

WisBlock DC Current Module

Model: RAK16000

RAK16002 is a part of the WisBlock Sensor Series that is capable of measuring battery charge in battery-powered handheld PC and portable product applications.

WisBlock Coulomb Sensor Module

Model: RAK16002

RAK18000 is a WisBlock Sensor PDM Stereo Microphone Module which add sound sensing capability on the WisBlock platform. It is based on the two MP34DT06J microphone modules.

WisBlock PDM Stereo Microphone Module

Model: RAK18000

RAK1901 is a WisBlock Sensor which extends the WisBlock system with a Sensirion SHTC3 temperature and humidity sensor. A ready to use SW library and tutorial makes it easy to build up an environmental temperature and humidity data acquisition system.

WisBlock Temperature and Humidity Sensor

Model: RAK1901

RAK1902 is a WisBlock Sensor which extends the WisBlock system with a ST KPS22HB barometric pressure sensor. A ready to use SW library and tutorial makes it easy to build up a barometric air pressure data acquisition system.

WisBlock Barometer Pressure Sensor Module

Model: RAK1902

RAK1903 is a WisBlock Sensor which extends the WisBlock system with a TI OPT3001DNPR light sensor. A ready to use SW library and tutorial makes it easy to build up an ambient light data acquisition system.

WisBlock Ambient Light Sensor Module

Model: RAK1903

RAK1904 is a WisBlock Sensor which extends the WisBlock system with a ST LIS3DH 3-axis acceleration sensor. A ready to use SW library and tutorial makes it easy to build up a motion detection and acceleration data acquisition system.

WisBlock 3-Axis Acceleration Sensor Module

Model: RAK1904

RAK1905 is a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer, part of the RAKwireless WisBlock Sensor series. It is based on MPU-9250 from TDK and designed for 9-axis motion tracking.

WisBlock 9-Axis Sensor Module

Model: RAK1905

RAK1906 is a WisBlock Sensor that extends the WisBlock system with a Bosch BME680 environment sensor. A ready-to-use SW library and tutorial make it easy to build a temperature and humidity data acquisition system.

WisBlock Environmental Sensor Module

Model: RAK1906

RAK1910 is a WisBlock sensor that extends the WisBlock system with a u-Blox MAX-7Q GPS module. A ready-to-use SW library and tutorial make it easy to build up a GPS-based location tracker.

WisBlock GNSS Location Module

Model: RAK1910

WisBlock Audio is a range of building blocks, including microphones, amplifiers DSP, and enclosures which add Audio to the WisBlock ecosystem. Use them to create innovative IoT applications, and they'll work seamlessly with any IoT network, such as Wifi, LoRaWAN, or cellular IoT.

WisBlock Audio Interposers are modules that allow you to connect multiple WisBlock Audio modules onto a single WisBlock Base IO slot. These modules also provide the connectivity you need when using multiple WisBlock Audio modules.

RAK18003 WisBlock Audio module is an interposer module that allows you to use multiple WisBlock Audio boards in a single IO slot.

WisBlock Audio Interposer Module

Model: RAK18003

WisBlock Audio Microphones are the ears for your WisBlock system. These are analog and digital microphones, which can be connected to a WisBlock Base IO slot or the WisBlock Audio Interposer connector are available.

RAK18030 is a WisBlock Audio that extends the WisBlock system based on SPK0641HT4H-1 from Knowles. It is a mono PDM microphone module with a ready-to-use SW library and tutorial, making it easy to achieve rich applications.

WisBlock Audio PDM Microphone Module

Model: RAK18030

RAK18031 is a WisBlock Audio that extends the WisBlock system based on MP34DT06JTR from ST. It is a mono PDM microphone module with a ready-to-use SW library and tutorial, making it easy to achieve rich applications.

WisBlock Audio PDM Microphone Module

Model: RAK18031

RAK18032 is a WisBlock Audio that extends the WisBlock system based on SPH0655LM4H-1 from Knowles. It is an ultrasonic PDM microphone module with a ready-to-use SW library and tutorial that makes it easy to achieve rich applications.

WisBlock Audio Ultrasonic Microphone Module

Model: RAK18032

RAK18033 is a WisBlock Audio Stereo Microphone Header module that allows you to connect two PDM Microphone modules to have stereo input.

WisBlock Audio Stereo Microphone Header Module

Model: RAK18033

RAK18040 is an analog microphone to the I2S module, part of the WisBlock Audio Series. It is designed based on NAU85L40B from Nuvoton, an audio ADC with an integrated frequency-locked loop (FLL) and microphone preamplifier.

WisBlock Audio Analog Microphone to I2S Module

Model: RAK18040

RAK18041 is a WisBlock Analog Microphone module that allows you to detect sound waves from the external environment.

WisBlock Analog Microphone Module

Model: RAK18041

WisBlock Audio Amplifiers are the voice of your WisBlock system. The Amplifier modules allow you to connect one or more speakers to a WisBlock Base IO slot or the WisBlock Audio Interposer connector.

RAK18060 is a stereo amplifier module, part of the WisBlock Audio Series. It is designed based on the TAS2560 from TI, which features an ultra-low-noise audio DAC and Class-D audio amplifier.

WisBlock Audio Stereo Amplifier Module

Model: RAK18060

RAK18061 is a mono amplifier module, part of the WisBlock Audio Series. It is designed based on the TAS2560 from TI, which features an ultra-low-noise audio DAC and Class-D audio amplifier.

WisBlock Audio Mono Amplifier Module

Model: RAK18061

WisBlock Audio DSP processes the audio received by the WisBlock Audio Microphones. This processing may be for voice or sound recognition.

RAK18080 is a professional audio processing module, part of the WisBlock Audio Series. The RAK18080 is designed based on DBM10L by Synaptics, which can enable AI/ML, voice, and sensor applications.

RAK18080 WisBlock Audio DSP Board Module

Model: RAK18080

WisBlock Interface modules provide your application with interfaces to other systems using digital and analog inputs and industry standards like RS485 or 4-20mA communication.

RAK12018 WisBlock Code Scanner Module is a WisBlock Interface module capable of scanning 1D or 2D codes. It uses the LV3296 scanner module from RAKINDA that works on bar codes, QR, and other standard 1D/2D codes.

RAK12018 WisBlock Code Scanner Module

Model: RAK12018

RAK13001 is a WisBlock Interface module which extends the WisBlock system that can isolate input and output between internal and external signal. It is used to programmatically switch on/off devices, which uses a high voltage or high current.

RAK13001 WisBlock Relay IO Module

Model: RAK13001

The RAK13002 is a WisBlock Core adaptor module that can be mounted to the IO slot of WisBlock Base board. This module exposed all WisBlock Core signals to male pin header, such as I2C, SPI, UART, GPIO, ADC, etc.

RAK13002 WisBlock IO Module

Model: RAK13002

The RAK13003 is an IO expansion module that can be mounted to IO slot of WisBlock Base board. It offers 16 bidirectional I/O ports by using MCP23017 IC from Microchip. The configuration of the module is via I2C interface and it supports both standard and fast I2C modes.

RAK13003 WisBlock IO Expansion Module

Model: RAK13003

The RAK13004 is a PWM expander module that can be mounted to the IO slot of WisBlock Base board. It can be controlled 16-channel LED, and the module uses PCA9685 from NXP, I2C interface.

RAK13004 WisBlock PWM Expander Module

Model: RAK13004

RAK13005 is a WisBlock Interface module that extends the WisBlock system with a LIN module. It is designed for in-vehicle networks using data transmission rates up to 20 kBaud.

RAK13005 WisBlock LIN Module

Model: RAK13005

RAK13006 is a WisBlock Interface module that extends the WisBlock system with a CAN communication capability. It supports both CAN 2.0B and CAN FD with an arbitration bit rate up to 1 Mbps.

RAK13006 WisBlock CAN Module

Model: RAK13006

RAK13007 is a WisBlock Interface module that extends the WisBlock system that can isolate the output between internal and external signals. It is used to programmatically switch on/off devices, which uses a high voltage or high current.

RAK13007 WisBlock Relay Module

Model: RAK13007

RAK13009 is a QWIIC module that provides interface for QWIIC connect sensors, actuators, shields, and cables.

RAK13009 WisBlock QWIIC Module

Model: RAK13009

RAK13010 is a WisBlock Interface module that extends the WisBlock system. It is an SDI-12 (Serial Digital Interface at 1200 baud rate) module, which is an asynchronous serial communications protocol for intelligent sensors that monitor environment data.

WisBlock SDI-12 Module

Model: RAK13010

RAK13800 WisBlock Ethernet Module is a WisBlock Interface module that extends the WisBlock system with an embedded Ethernet Controller. This module is designed as a full hardwired one-chip TCP/IP solution.

WisBlock Ethernet Module

Model: RAK13800

RAK14002 is a WisBlock Touch Sensor which extends the WisBlock with a 3-channel Capacitive Touch Sensor. A ready to use SW library and tutorial makes it easy to add a capacitive touchpad to your project.

WisBlock Touch Sensor Module

Model: RAK14002

RAK14004 is a WisBlock Interface module, which extends the WisBlock system with a keypad interface.

WisBlock Keypad Module

Model: RAK14004

RAK14006 is a rotary encoder module that can detect user inputs.

WisBlock Rotary Encoder Module

Model: RAK14006

RAK14007 is a WisBlock Interface Module where you can connect the separate sensor PCB, which is the RAK14007 Wisblock Joystick Module.

WisBlock Interface Module

Model: RAK14007

RAK14009 is a 3x3 keypad module designed to be part of a production-ready IoT solution and must be combined with a RAK14004 WisBlock Keypad Module.

WisBlock 3x3 Keypad Module

Model: RAK14009

RAK14010 is a 3x4 keypad module designed to be part of a production-ready IoT solution and must be combined with a RAK14004 WisBlock Keypad Module.

WisBlock 3x4 Keypad Module

Model: RAK14010

RAK14011 is a 4x4 keypad module designed to be part of a production-ready IoT solution and must be combined with a RAK14004 WisBlock Keypad Module.

WisBlock 4x4 Keypad Module

Model: RAK14011

RAK14013 is a joystick module with embedded MCU based on ATTINY441-SSU from Atmel.

WisBlock Joystick Module

Model: RAK14013

RAK16001 is an Analog-to-Digital (ADC) module, which uses an ADS7830 from Texas Instruments that can measure 8-independent voltages or 4-independent differential voltages. The ADS7830 is an 8-bit ADC module that features a serial I2C interface and an 8-channel multiplexer.

WisBlock ADC Module

Model: RAK16001

RAK1920 is a WisBlock Interface module, which extends the WisBlock system with an adapter board to connect Click Boards (MikroElektronika), QWICC (Sparkfun) based and Grove (Seeed) based sensors to WisBlock.

WisBlock Sensor Adapter Module

Model: RAK1920

RAK5801 is a WisBlock Interface module that extends the WisBlock system with a 4-20mA current to voltage converter. It supports up to two 4-20mA interfaces and voltage supply for connected sensors.

WisBlock 4-20mA Interface Module

Model: RAK5801

RAK5802 is a WisBlock Interface module, which extends the WisBlock system with an industry standard RS485 to serial converter. It supports one RS485 port and voltage supply for connected sensors.

WisBlock RS485 Interface Module

Model: RAK5802

RAK5804 is a WisBlock Interface module which extends the WisBlock system with additional analog and digital interfaces. In addition, it provides an USB interface.

WisBlock Interface Extension Module

Model: RAK5804

RAK5811 is a WisBlock Interface module which extends the WisBlock system with 2 analog input ports. The analog ports have a 0-5V input range and are connected to the WisBlock Core MCU’s analog inputs.

WisBlock 0-5V Interface Module

Model: RAK5811

WisBlock Display modules add visual display options to WisBlock. WisBlock Display offers graphic displays and LED’s for WisBlock solutions.

RAK14000 is a WisBlock Display module which consists of an E-Ink Display and Three-Button Module.

WisBlock E-Ink Display

Model: RAK14000

The RAK14001 is an RGB LED module capable of driving the RGB LEDs up to 20mA per segment via the I2C interface. It uses the NCP5623B of On Semiconductors that has a built−in DC/DC converter.

WisBlock RGB LED Module

Model: RAK14001

RAK14003 is a WisBlock LED Bar Graph module that can be used to build a multipurpose graphic feedback display.

WisBlock LED Bar Graph Module

Model: RAK14003

RAK14012 is an LED matrix driver module for WS2812B LEDs.

WisBlock LED Matrix

Model: RAK14012

RAK14014 is a WisBlock Display module that extends the WisBlock system. Moreover, it can display not just text, but elaborate colorful graphic displays. The display is a 2.4-inch active area and contains 240x320 pixels.

WisBlock TFT LCD Display Module

Model: RAK14014

RAK1921 is a WisBlock Display module, which extends the WisBlock system with an OLED display. A ready to use SW library and tutorial makes it easy to visualize data of your WisBlock solution.

WisBlock OLED Display

Model: RAK1921

WisBlock Extra modules are add-ons for WisBlock. This category includes extension cables, real-time clock, and other useful modules.

The RAK12002 is a Real-Time Clock module, part of the RAK Wireless WisBlock Series. The RTC chip is an RV-3028-C7 from Micro Crystal and uses the I2C interface.

WisBlock RTC Module

Model: RAK12002

RAK18001 is a WisBlock Extra Buzzer module which produces an audible sound using the MLT-5020 Buzzer.

WisBlock Buzzer Module

Model: RAK18001

RAK19005 is a WisBlock FPC (Flat Printed Circuit) extension cable for Slot A to D WisBlock modules.

WisBlock Sensor Extension Cable

Model: RAK19005

RAK19008 is a FPC (Flat Printed Circuit) extension cable for IO Slot of WisBlock Base Board.

WisBlock IO Extension Cable

Model: RAK19008

RAK5814 is a crypto module, part of the WisBlock Module Series. It was designed to be secured with hardware-based key storage. The crypto chip is ATECC608A from Microchip.

WisBlock Crypto Module

Model: RAK5814

WisBlock Storage extends the memory capabilities of WisBlock solutions with different storage options like Flash, EEPROM, or SD-Card slots.

The RAK15000 is a serial EEPROM module that can be mounted on slot A, B, C, or D of the RAK5005-O base board. It provides 2 Mbit (262,144 x 8) of serial EEPROM. The module uses AT24CM02 from Microchip and supports I2C standard and fast mode.

WisBlock EEPROM Module

Model: RAK15000

The RAK15001 is a WisBlock NOR Flash Module. It uses GD25Q16CNIG (16Mbit) from GigaDevice and is configured via standard SPI interface.

WisBlock Flash Module

Model: RAK15001

The RAK15002 is a Micro SD card module that can be mounted to the IO slot of the WisBlock Base board. This module uses a 4-line SPI interface to access the SD card and supports the card insert detection feature.

WisBlock Micro SD Card Module

Model: RAK15002

RAK15003 is a WisBlock FRAM module that extends the WisBlock system with an MB85RC256VPNF-G-JNERE1 memory module from Fujitsu.

RAK15003 WisBlock 32kByte FRAM Module

Model: RAK15003

RAK15004 is a WisBlock FRAM Storage Module based on MB85RC512T 512Kbit (64K x 8) from FUJITSU. It is a very high endurance nonvolatile memory storage chip and can be interfaced via I2C and support High Speed-Mode at 3.4 MHz.

RAK15004 WisBlock FRAM Module

Model: RAK15004

RAK15005 is a WisBlock 128kByte FRAM module that extends the WisBlock system with a MB85RC1MTPNF memory module from Fujitsu.

RAK15005 WisBlock 128kByte FRAM Module

Model: RAK15005

RAK15006 is a WisBlock 512kByte FRAM module that extends the WisBlock system with an MB85RS4MT memory module from Fujitsu.

RAK15006 WisBlock 512kByte FRAM Module

Model: RAK15006

RAK15007 is a WisBlock 1MByte FRAM module that extends the WisBlock system with an CY15B108QN memory module from Cypress.

RAK15007 WisBlock 1MByte FRAM Module

Model: RAK15007

WisBlock Power Modules extend the power supply options available for WisBlock. Whether you need wireless charging or want to use an alternative green energy resource, the WisBlock Power Modules offer you such solutions. Moreover, a power supply option for external sensors is available as well.

RAK19002 is a WisBlock Power that supplies 12V DC with up to 50mA. The main purpose is to have 12V power supply for external sensors that are connected to WisBlock.

RAK19002 WisBlock Boost Module

Model: RAK19002

RAK19004 is a WisBlock Power module that can harness and convert green power such as wind power, hydroelectric power, or solar power into fixed 5V output.

RAK19004 WisBlock Green Power Module

Model: RAK19004

RAK19006 is a WisBlock Power that charges the battery wirelessly. It is highly efficient and supports up to 5W applications.

RAK19006 WisBlock Wireless Charge Module

Model: RAK19006

RAK19018 is a PoE Module that extracts power from an ethernet cable. This module is based on the Silvertel Ag9905MT converter board and compatible with the IEEE 802.3af PoE standard.

RAK19018 WisBlock PoE Module for RAK13800

Model: RAK19018

WisBlock Motor Modules adds the capability to control electric motors for your robot project and actuator applications.

RAK17000 is a WisBlock Motor Control Module that easily drives one stepper motor or two DC motors.

RAK17000 WisBlock Motor Control Module

Model: RAK17000

RAK17001 is a WisBlock H-Bridge module that extends the WisBlock system with a STSPIN250 DC motor drive module from ST. It can drive DC motors and can be used as a PWM controller.

WisBlock H-Bridge Module

Model: RAK17001

WisBlock Solutions are ready-to-use products built with WisBlock modules. They come in an enclosure and include firmware already. The firmware is open source and available on our Github WisBlock Repo.

RAK10700 WisBlock Solution LPWAN Tracker is a ready-to-use WisBlock Solution. It is a location tracker built with WisBlock modules - RAK4631 Core module, the RAK12500 GNSS location module, the RAK1906 environment sensor, and the RAK1904 3-axis acceleration sensor. It comes assembled in an IP65 enclosure.

WisBlock GNSS Tracker for LoRaWAN

Model: RAK10700

RAK10702 is a full WisBlock Base board that has one Core slot, two IO slots, and six sensor slots for WisBlock modules. It also provides the power supply for attached WisBlock modules.

WisBlock Indoor Comfort Node

Model: RAK10702

WisBlock Kits are collections of WisBlock Modules designed to work on different applications like Industrial, Health monitoring, Movement detection, and others. It also features connectivity like LoRa/LoRaWAN, Cellular IoT, and BLE.

The WisBlock IoT Starter Kit is a comprehensive and customizable kit that includes a range of connectivity options (LoRaWAN, BLE, LTE-M/NB-IoT) and multiple modules (temperature/humidity, accelerometer, barometer, ambient light, GPS) to enable users to quickly develop and prototype their own IoT applications.

WisBlock IoT Starter Kit

Model: Starter

The WisBlock Outdoor Location Tracker Kit is an IoT kit based on two accurate GPS/GNSS moduels, Accelerometers and 9-DOF sensors that can be used on outdoor location tracking. It also supporst connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Outdoor Location Tracker Kit

Model: Outdoor Tracking

The WisBlock Environment Sensor Kit is a comprehensive kit that includes sensors for monitoring environmental conditions like temperature, humidity, pressure, UV, CO2, Particulate Matter, VOC and IAQ. It supports different connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Environment Sensor Kit

Model: Environment

The WisBlock Biometric Monitoring Kit is a comprehensive and customizable IoT kit that includes biometric sensors for monitoring heart rate, blood oxygen levels, as well as body temperature, and supports different connectivity options like LoRaWAN, BLE, LTE-M and NB-IoT.

WisBlock Biometric Monitoring Kit

Model: Biometric

The WisBlock Movement Detection Kit is a comprehensive and customizable IoT kit that includes contact and non-contact motion sensors like accelerometers, gyroscope, PIR and radar. It also supports different connectivity options like LoRaWAN, BLE, LTE-M and NB-IoT.

WisBlock Movement Detection Kit

Model: Movement

The WisBlock Industrial 4.0 Kit is an IoT kit that includes a range of sensors (inductive, proximity, fork, and current/coulomb) and interfaces used in industrial settings (relays, joystick, and barcode scanner). It also supports different connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Industrial 4.0 Kit

Model: Industry 4.0

The WisBlock Home Office Security Kit is a comprehensive IoT kit that focuses on detecting intrusion (PIR, Radar, Ultrasonic) and access control (Fingerprint, NFC, Barcode) for homes and offices, It also supports different connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Home and Office Security Kit

Model: Security

The WisBlock Light and Color Kit is a comprehensive IoT kit which includes RGB, Visible, and UV light sensors and LED Bar/RGB modules. It also supports different connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Light and Color Kit

Model: Light and Color

The WisBlock Agriculture Kit is an IoT kit optimized for agricultural applications which includes soil, light, and environment sensors as well as common interfaces like SDI-12, 4-20mA and RS485. It also supports different connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Agriculture Kit

Model: Agriculture

The WisBlock Industrial IO and Communication Kit is a comprehensive IoT kit that includes LIN, CAN, SDI-12, 4-20mA, RS485, Analog, and Relay interfaces. It also supports different connectivity options like LoRaWAN, BLE, LTE-M, NB-IoT, and PoE Ethernet.

WisBlock Industrial IO and Communication Kit

Model: Industrial IO and Communication Interfaces

The WisBlock Indoor Location Tracker Kit is an IoT kit based on UWB technology, Accelerometers, and 9-DOF sensors optimized of indoor location tracking. It also support connectivity options like LoRaWAN, BLE, LTE-M, and NB-IoT.

WisBlock Indoor Location Tracker Kit

Model: Indoor Tracking

WisBlock Unify Enclosure is designed specifically for WisBlock Modules. It supports different mounting accessory options both for indoor and outdoor IoT device deployments.

RAKBox Accessories shows the different mounting options of the accessories included in the WisBlock Unify Enclosures.

WisBlock Unify Enclosure Accessories

Model: RAKBox-Accessories

RAKBox-UO100x75x38 is a small-sized WisBlock Unify Enclosure with a solar panel for powering up your devices and charging the batteries. It is an IP65-rated protection class that allows the unit to be used outdoors while protecting the internal components from dust and water.

WisBlock Unify Outdoor Enclosure 100x75x38 with Solar Panel

Model: RAKBox-UO100x75x38 with Solar Panel

RAKBox-UO100x75x38 is a small-sized WisBlock Unify Enclosure. It is an IP67-rated protection class that allows the unit to be used outdoors while protecting the internal components from dust and water.

WisBlock Unify Outdoor Enclosure 100x75x38

Model: RAKBox-UO100x75x38

RAKBox-UO150x100x45-Solar is a mediuim-sized WisBlock Unify Enclosure with a solar panel for powering up your devices and charging the batteries. It is an IP65-rated protection class that allows the unit to be used outdoors while protecting the internal components from dust and water.

WisBlock Unify Outdoor Enclosure 150x100x45 with Solar Panel

Model: RAKBox-UO150x100x45 with Solar

RAKBox-UO150x100x45 is a medium-sized WisBlock unify enclosure. It is an IP67-rated protection class that allows the unit to be used outdoors while protecting the internal components from dust and water.

WisBlock Unify Outdoor Enclosure 150x100x45

Model: RAKBox-UO150x100x45

RAKBox-UO180x130x60 is a large-sized WisBlock unify enclosure. It is an IP67-rated protection class that allows the unit to be used outdoors while protecting the internal components from dust and water.

WisBlock Unify Outdoor Enclosure 180x130x60

Model: RAKBox-UO180x130x60
